Overview

l 1G1F+VOIP is designed as HGU (Home Gateway Unit) in transfer data FTTH solutions; the carrier-class FTTH application provides data service access.

l 1G1F+VOIP is based on mature and stable, cost-effective XPON technology. It can switch automatically with EPON and GPON mode when it access to the EPON OLT or GPON OLT.

l 1G1F+VOIP adopts high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees to meet the technical performance of the module of China telecommunications EPON CTC3.0.

l 1G1F+VOIP is fully compliant with technical regulations such as ITU-T G.984.x and IEEE802.3ah.

Feature

l Supports Dual Mode (can access GPON/EPON OLT).

l Supports GPON G.984/G.988 standards.

l Support SIP Protocol for VoIP Service.

l Integrated line testing compliant with GR-909 on VOIP.

l Support 802.11n WIFI (2x2 MIMO) function.

l Support NAT, Firewall function.

l Support Flow & Storm Control , Loop Detection, Port Forwarding and Loop-Detect.

l Support port mode of VLAN configuration.

l Support LAN IP and DHCP Server configuration.

l Support TR069 Remote Configuration and WEB Management.

l Support Route PPPOE/IPOE/DHCP/Static IP and Bridge mixed mode.

l Support IPv4/IPv6 dual stack.

l Support IGMP transparent/snooping/proxy.

l In compliant with IEEE802.3ah standard.

l Compatible with popular OLT(HW, ZTE)
